Polestar 2 & 3 Charging Adapter Guide:
J1772, CCS1 & Tesla Supercharger Access (2026)
Last updated: May 2026 · 8 min read · ChargePapa Team
The Polestar 2 and Polestar 3 use CCS1 in the US — they accept J1772 Level 2 connectors natively and support DC fast charging up to 205 kW (Polestar 2) or 250 kW (Polestar 3). For Tesla Supercharger access, current CCS1 models need a NACS-to-CCS1 adapter rated to handle those peak outputs without throttling.
Polestar 2 / 3 CCS1 / NACS Adapter Guide
Both the Polestar 2 and Polestar 3 use the CCS1 (Combined Charging System, Type 1) port in North America. CCS1 includes the J1772 AC interface in its upper connector section — any J1772 Level 2 EVSE plugs directly into both Polestar models without an adapter. The two DC pins at the bottom engage only during DC fast charging sessions.
What Charging Port Does the Polestar 2 and Polestar 3 Use?
| Model |
Battery (usable) |
DC Max (CCS1) |
AC Max |
US Connector |
| Polestar 2 Standard Range Single Motor |
69 kWh |
130 kW |
11 kW |
CCS1 |
| Polestar 2 Long Range Single Motor |
82 kWh |
130 kW |
11 kW |
CCS1 |
| Polestar 2 LR Dual Motor (2021–2022) |
78 kWh |
155 kW |
11 kW |
CCS1 |
| Polestar 2 LR Dual Motor (2023+) |
82 kWh |
205 kW |
11 kW |
CCS1 |
| Polestar 3 LR Dual Motor |
111 kWh |
250 kW |
11 kW |
CCS1 |
| Polestar 3 LR Dual Motor w/ Performance |
111 kWh |
250 kW |
11 kW |
CCS1 |
Note on future NACS models
Polestar has announced NACS adoption for future model years. Verify your specific model year’s port type in the vehicle settings or at polestar.com before purchasing an adapter.
Can a Polestar 2 or Polestar 3 Charge at Tesla Superchargers?
Yes — Tesla opened its Supercharger network to non-Tesla EVs, and Polestar owners with CCS1 vehicles can access participating stations through the Tesla app. The process depends on the station type:
Magic Dock Stations
Tesla’s Magic Dock locations include a built-in NACS-to-CCS1 adapter that deploys for non-Tesla vehicles. No hardware required, but Magic Dock is not available at every Supercharger location — check the Tesla app map for the non-Tesla charging icon.
Standard NACS Supercharger Cables
A NACS-to-CCS1 adapter is required. Once connected, the session is initiated via the Tesla app. The adapter must handle the Polestar’s full DC peak — 205 kW for Polestar 2 (2023+) or 250 kW for Polestar 3.
| Scenario |
Adapter Needed? |
Session Start |
| CCS1 Polestar at Magic Dock Supercharger |
Built-in adapter |
Tesla App |
| CCS1 Polestar at standard NACS Supercharger |
NACS to CCS1 adapter required |
Tesla App |
| Future NACS Polestar at any Supercharger |
None |
Tesla App or Polestar account |
NACS-to-CCS1 Adapter for Polestar 2 and 3 — Why the Rating Matters
The Polestar 3 is the highest DC fast-charging Polestar model currently available, at 250 kW peak. That draw is 250A at 1000V — an adapter rated below that will throttle output at the point where Polestar charging is fastest. The Polestar 2 (2023+ Long Range Dual Motor) peaks at 205 kW.
An undersized adapter on a Polestar 3 at a V4 Supercharger (up to 350 kW capacity) limits what the car actually receives, defeating the purpose of using a high-output charger.
Rated 500A / 1000V DC with a maximum power throughput of 350 kW — above the Polestar 3’s 250 kW peak and well above the Polestar 2’s 205 kW ceiling. No throttling at either model’s maximum draw. SKU: CPCADA0030.
View DC-Link 500A
-
Current rating: 250A min (Polestar 3 peak) — 500A rated = full headroom
-
Voltage: 1000V DC minimum
-
IP rating: IP54 minimum; IP65 preferred for rain charging
-
Shell: UL-rated thermoplastic (not standard ABS)
Polestar 2 and 3 Level 2 Home Charging — No Adapter Needed
No adapter needed
Both the Polestar 2 and Polestar 3 have an 11 kW onboard AC charger in their US configurations. The CCS1 port accepts J1772 Level 2 connectors natively — home wallboxes, public Level 2 stations, and portable EVSEs all plug in without modification.
-
Polestar 2 LR (82 kWh): 10% to 80% approx. 5 hours at 11 kW
-
Polestar 3 (111 kWh): 10% to 80% approx. 6.5 hours at 11 kW
Level 2 charging adds roughly 32–38 miles of range per hour for both models at 11 kW depending on efficiency and ambient temperature.
-
32A EVSE on 40A circuit: approx. 7.7 kW, approx. 22 mi/hr
-
48A EVSE on 60A circuit: 11 kW (OBC ceiling), approx. 35 mi/hr
NEC Article 625: EV circuits must be rated at 125% of continuous draw. A 48A EVSE requires a 60A dedicated breaker.
Polestar 2 and 3 Charging Network Compatibility
Both models charge natively at every major CCS1 network in North America — no adapter needed for Electrify America, EVgo, ChargePoint, Blink, or any public CCS1 fast charger. The Polestar 3 at 250 kW can take full advantage of Electrify America’s 350 kW stations, delivering one of the fastest public charging sessions available on any CCS1 vehicle.
| Network |
Connector |
Polestar 2 / 3 (CCS1) |
Notes |
| Home J1772 wallbox |
J1772 (via CCS1) |
Native |
No adapter needed |
| Electrify America |
CCS1 |
Native |
Polestar 3 uses up to 250 kW — fastest CCS1 car on EA |
| EVgo |
CCS1 |
Native |
— |
| ChargePoint |
CCS1 |
Native |
— |
| Blink |
CCS1 |
Native |
— |
| Tesla Supercharger (Magic Dock) |
NACS/CCS1 |
Via Magic Dock + Tesla App |
Not available at all stations |
| Tesla Supercharger (standard NACS) |
NACS |
NACS to CCS1 adapter needed |
DC-Link covers full 250 kW |
Polestar 2 vs Polestar 3 — Same Adapter, Different Peak Speeds
Both the Polestar 2 and Polestar 3 use identical CCS1 ports, and the same NACS-to-CCS1 adapter covers both models. The only meaningful difference is peak DC speed: the Polestar 3 draws up to 250 kW while the Polestar 2 Long Range Dual Motor (2023+) draws up to 205 kW.
Polestar 3 at V4 Supercharger
DC peak: 250 kW / 250A at 1000V
10–80% time: approx. 25 minutes
500A adapter = zero throttling
Polestar 2 (2023+) at V3 Supercharger
DC peak: 205 kW / 205A at 1000V
10–80% time: approx. 22 minutes
500A adapter = zero throttling
Both require the session to be initiated via the Tesla app. The ChargePapa DC-Link (500A / 350 kW) covers both models at their respective peaks with no throttling.
-
500A / 1000V — covers Polestar 3 (250 kW) and Polestar 2 (205 kW) at peak
-
350 kW maximum — above V4 Supercharger output
-
IP65 — fully weatherproof
-
UL94 V-0 thermoplastic shell
View DC-Link 500A
Related: Mercedes EQS & EQE Charging Adapter Guide · BMW i4 Charging Adapter Guide
Frequently Asked Questions
Does the Polestar 2 need a J1772 adapter for home or public Level 2 charging?
No. The Polestar 2 and Polestar 3 use a CCS1 port that is fully compatible with J1772 Level 2 connectors at the socket level. Any J1772 EVSE — home wallbox, hotel charging station, or public Level 2 charger — plugs directly into both Polestar models without modification.
Can a Polestar 2 or Polestar 3 charge at Tesla Superchargers?
Yes. CCS1 Polestar models can use Tesla Superchargers at Magic Dock locations via the Tesla app without any adapter. At standard NACS Supercharger cables, a NACS-to-CCS1 adapter is required. The adapter must handle at least 205 kW (Polestar 2) or 250 kW (Polestar 3) to avoid throttling.
What NACS-to-CCS1 adapter works with the Polestar 3’s 250 kW charging?
The adapter needs a current rating of at least 250A to pass the Polestar 3’s peak DC draw without throttling. The ChargePapa DC-Link (CPCADA0030) is rated for 500A and 1000V DC, with a 350 kW ceiling — above the Polestar 3’s 250 kW peak. It also covers the Polestar 2 at 205 kW.
What is the maximum DC charging speed for the Polestar 2 and Polestar 3?
The Polestar 3 (both trims) accepts up to 250 kW at CCS1 DC fast chargers — one of the highest in the CCS1 segment. The Polestar 2 Long Range Dual Motor (2023+) accepts up to 205 kW; earlier Polestar 2 variants cap at 155 kW or 130 kW depending on configuration. All US models have an 11 kW onboard AC charger.
Does the same adapter work for both Polestar 2 and Polestar 3?
Yes. Both models use identical CCS1 ports — one adapter covers the entire current Polestar lineup. The difference is peak speed: 250 kW for the Polestar 3 and up to 205 kW for the 2023+ Polestar 2. A 500A-rated adapter handles both without throttling at any Supercharger output level.
The Polestar 3 is one of the fastest-charging CCS1 vehicles available — 250 kW DC, 11 kW AC Level 2, and full access to Electrify America and Tesla Supercharger networks. For Polestar 2 and 3 owners who want reliable Supercharger access beyond Magic Dock locations, the ChargePapa DC-Link NACS-to-CCS1 adapter is rated for 500A and 350 kW — headroom above the Polestar 3’s 250 kW peak and the Polestar 2’s 205 kW ceiling.
