  • Type 1 to Type 2 Adapter (32A / AC 110-250V) Detail Watermark
1 4

ChargePapa Power-Bridge | Type 1 to Type 2 Adapter (32A / AC 110-250V)

On sale Save $29.00 USD (20% off)
$114.55 USD
$143.55 USD $114.55 USD
Sale Sold out
Shipping calculated at checkout.
🛡️ Quality Assurance: Every unit undergoes a rigorous 72-hour high-voltage stress test and thermal calibration before dispatch from our global hub. Safety is our priority; quality is non-negotiable.
✅ CE/TUV Safety Certified
🛡️ 2-Year Replacement Warranty
📦 Free Global Shipping

Power-Bridge | Type 1 (SAE J1772) → Type 2 (IEC 62196-2) Adapter


The ChargePapa Power-Bridge CP-KL-ADP-021 enables SAE J1772 Type 1 electric vehicles to charge at IEC 62196-2 Type 2 AC stations — the dominant charging standard across Europe and increasingly common worldwide. With wide-voltage support from AC 110V to 250V and a 32A maximum current rating, this adapter bridges North American and European EV infrastructure without compromise. Built with silver-plated copper alloy conductors and a rugged PC+PA66 housing, it is engineered for over 10,000 charge cycles in all weather conditions.

Type 1 to Type 2 Adapter (32A / AC 110-250V)

Engineering Data Sheet
SKU CP-KL-ADP-021
Input Connector IEC 62196-2 Type 2 (Female) — Station Side
Output Connector SAE J1772 Type 1 (Male) — Vehicle Side
Working Voltage AC 110V ~ 250V (Wide Voltage)
Rated Current 32A MAX
Max Power Output ~7.4 kW @ 230V · ~3.5 kW @ 110V (Single-phase)
Phase Type Single-phase
Terminal Temp Rise <50K
Case Material PC + PA66
Conductor Material Copper alloy with silver plating
Insertion Force 45N < F < 100N
Plug/Unplug Life >10,000 cycles
Working Temperature -30°C to +50°C (-22°F to +122°F)
Working Humidity 5% ~ 95% RH
Working Altitude ≤2000m
Compatibility
Station Side (Input) Vehicle Side (Output) Charging Type
IEC 62196-2 Type 2 AC Station SAE J1772 Type 1 EV Port AC Level 2 Only
Compatible with SAE J1772 Type 1 EVs including Toyota Prius Prime, Mitsubishi Outlander PHEV, Nissan Leaf (older models), Chevrolet Volt, Ford C-Max Energi, and other North American / Japanese-standard vehicles.
✅ Standards & Certifications

CE — Conformité Européenne: Meets EU safety, health, and environmental protection requirements for electrical equipment.

FCC — Federal Communications Commission: Compliant with electromagnetic interference standards for use in North America.

Frequently Asked Questions

Q: Which vehicles are compatible with the CP-KL-ADP-021?

A: The ChargePapa Power-Bridge CP-KL-ADP-021 is compatible with all SAE J1772 Type 1 electric vehicles, including Toyota Prius Prime, Mitsubishi Outlander PHEV, Nissan Leaf (pre-2019 models), Chevrolet Volt, Ford C-Max Energi, and other North American and Japanese-standard EVs. It allows these vehicles to charge at any IEC 62196-2 Type 2 AC station.

Q: What is the maximum charging speed with the CP-KL-ADP-021?

A: The ChargePapa Power-Bridge supports up to 32A MAX. At AC 230V this delivers approximately 7.4 kW; at AC 110V approximately 3.5 kW. Actual charging speed is limited by your vehicle's onboard charger capacity and the station's output rating.

Q: How does this compare to a standard 16A Type 1 to Type 2 adapter?

A: Compared to standard 16A adapters, the ChargePapa CP-KL-ADP-021 delivers 100% more current capacity at 32A MAX, significantly reducing charge time for vehicles that support higher AC input. The wide-voltage design (AC 110V~250V) also makes it compatible with both North American and European grid voltages — a key advantage over single-voltage alternatives.

Q: Is this adapter CE and FCC certified?

A: Yes. The CP-KL-ADP-021 carries CE (Conformité Européenne) certification for EU safety and environmental compliance, and FCC (Federal Communications Commission) certification for electromagnetic compatibility in North America.

Q: Does this adapter support DC fast charging?

A: No. The CP-KL-ADP-021 supports AC Level 2 single-phase charging only. For DC fast charging solutions, please refer to ChargePapa's DC-Link adapter series.

Q: Can I use this adapter in both North America and Europe?

A: Yes. The CP-KL-ADP-021 features wide-voltage support from AC 110V to 250V, making it compatible with both North American (110-120V) and European (220-240V) grid standards. This makes it an ideal travel companion for SAE J1772 Type 1 EV owners visiting or relocating to Europe where IEC 62196-2 Type 2 stations are standard.

⚠️ Critical Usage Note

This adapter is designed for AC Level 2 single-phase charging only. Do not use with DC fast chargers or three-phase AC stations.

Always verify that your charging station output does not exceed 32A before use. Exceeding rated parameters may cause damage and will void the warranty.

Warranty & Assurance

2-Year Comprehensive Warranty.
We cover all internal component failures. If a fault occurs, we provide remote diagnosis and free replacement units or parts. No return shipping required for confirmed defects.

Shipping & Lead Time

Factory Direct Shipping.
• Processing (QC): 3-5 Business Days
• Global Transit: 8-20 Business Days
• Tracking provided via email upon dispatch.

Global Shipping & Fulfillment

Shipped Direct: Estimated timelines vary by product type.

Total turnaround may vary because product categories have different warehouse stock levels, quality-control procedures, and dispatch preparation cycles before shipment.

Adapters & Accessories

12-22 Business Days

Handling 4-7 business days + transit 8-15 business days.

Portable, Home & DC Chargers

15-29 Business Days

Handling 7-14 business days + transit 8-15 business days.

🏭 The Direct Process

To ensure safety and performance, ChargePapa products go through inspection, preparation, and dispatch coordination before shipment. Different product types may require different warehouse allocation and quality-control turnaround before release.

PART 1 Estimated Handling Time Before Dispatch

Tier 1

Adapters & Accessories

4-7 Business Days

For charging adapters, connector accessories, and related small parts. This handling window remains unchanged.

Tier 2

Portable Chargers, Home Chargers & DC Chargers

7-14 Business Days

For portable EV chargers, home charging stations, and DC charger models including DC SVC-TG and DC EVC-ZG. Additional preparation time is required before dispatch.

PART 2 Transit Time (8-15 Days)

Global Transport

8-15 Days

International transport via Air Freight, Sea Freight, or Land depending on destination and local delivery conditions.

Estimated Timeline by Product Type

Longer total timelines do not mean inactive processing. They reflect differences in stock allocation, warehouse readiness, product inspection workload, and dispatch turnover by category.

Product Type Handling Time Transit Time Estimated Total
Adapters & Accessories 4-7 business days 8-15 business days 12-22 business days
Portable EV Chargers 7-14 business days 8-15 business days 15-29 business days
Home Charging Stations 7-14 business days 8-15 business days 15-29 business days
DC Chargers / DC SVC-TG / DC EVC-ZG 7-14 business days 8-15 business days 15-29 business days

Remote Areas & Extended Delivery

Deliveries to remote regions, island destinations, low-frequency carrier zones, or special-route areas may require additional transit time beyond the standard estimate.

Depending on destination access and local logistics availability, shipments may be routed through a combination of air freight, sea freight, and land transport to complete final delivery safely and efficiently.

Logistics & Protection

Global Shipping Protection (Included)

All international orders are automatically insured against loss or damage. We handle claims with transport partners at no extra cost to you.

Multi-Modal Transport

We utilize a combination of Air, Sea, and Land transport networks to ensure secure delivery to your specific address.

Tracking Information

Tracking numbers are generated after handling is complete. Adapters and accessories usually receive tracking within 4-7 business days, while portable chargers, home charging stations, and DC charger orders may require 7-14 business days before tracking becomes active.

Customs & Duties

We handle export paperwork. However, specific local import duties or taxes are the recipient's responsibility.

* Product-specific handling times apply before transit begins.

* Orders placed on weekends or holidays will be processed on the next business day.

* Remote regions, islands, and special-route destinations may require additional transit time.

* During high-volume periods such as Black Friday or New Year, handling and transit may require additional time.

* Neither party shall be liable for delays resulting from force majeure events, including natural disasters, strikes, customs holds, or transport disruption.

Need a status check on your order timeline?

Contact our logistics team if your tracking update is taking longer than the estimated handling window for your product type.

✉ info@chargepapa.com

Will this fit my car?

Please verify your car's port type (Type 1 vs Type 2) before purchasing. If unsure, send a photo of your charging port to our chat support.
