Power-Bridge | Type 1 (SAE J1772) → GB/T (GB/T 20234.2) Adapter
The ChargePapa Power-Bridge CP-KL-ADP-022 enables GB/T 20234.2 electric vehicles to charge at SAE J1772 Type 1 AC charging stations — the standard Level 2 charging infrastructure across North America and Japan. Ideal for Chinese-standard EV owners traveling or relocating to North America or Japan, this adapter delivers up to 32A MAX with wide-voltage support from AC 110V to 250V. Built with silver-plated copper alloy conductors and a rugged PC+PA66 housing, it is rated for over 10,000 charge cycles.
| SKU | CP-KL-ADP-022 |
| Input Connector | SAE J1772 Type 1 (Female) — Station Side |
| Output Connector | GB/T 20234.2 (Male) — Vehicle Side |
| Working Voltage | AC 110V ~ 250V (Wide Voltage) |
| Rated Current | 32A MAX |
| Max Power Output | ~7.4 kW @ 230V · ~3.5 kW @ 110V (Single-phase) |
| Phase Type | Single-phase |
| Terminal Temp Rise | <50K |
| Case Material | PC + PA66 |
| Conductor Material | Copper alloy with silver plating |
| Insertion Force | 45N < F < 100N |
| Plug/Unplug Life | >10,000 cycles |
| Working Temperature | -30°C to +50°C (-22°F to +122°F) |
| Working Humidity | 5% ~ 95% RH |
| Working Altitude | ≤2000m |
| Station Side (Input) | Vehicle Side (Output) | Charging Type |
|---|---|---|
| SAE J1772 Type 1 AC Station | GB/T 20234.2 EV Port | AC Level 2 Only |
| Compatible with GB/T 20234.2 electric vehicles including BYD Atto 3, BYD Han, NIO ES6, NIO ET7, Xpeng P7, Li Auto L9, and other Chinese-standard EVs. Designed for use at SAE J1772 Type 1 Level 2 AC stations in North America and Japan. | ||
CE — Conformité Européenne: Meets EU safety, health, and environmental protection requirements for electrical equipment.
FCC — Federal Communications Commission: Compliant with electromagnetic interference standards for use in North America.
Q: Which vehicles are compatible with the CP-KL-ADP-022?
A: Any EV with a GB/T 20234.2 port — including BYD Atto 3, BYD Han, NIO ES6, NIO ET7, Xpeng P7, Li Auto L9, and other Chinese-standard EVs. This adapter allows these vehicles to charge at SAE J1772 Type 1 AC stations in North America and Japan.
Q: Which charging stations does the CP-KL-ADP-022 work with?
A: Works with SAE J1772 Type 1 AC Level 2 stations — the standard public and home charging infrastructure across North America and Japan. Does not support DC fast charging.
Q: What is the maximum charging speed with the CP-KL-ADP-022?
A: Up to 32A MAX — approximately 7.4 kW at 230V or 3.5 kW at 110V. Compared to standard 16A adapters, the CP-KL-ADP-022 delivers 100% more current capacity, significantly reducing charge time for vehicles that support higher AC input.
Q: Does this adapter support DC fast charging?
A: No. The CP-KL-ADP-022 supports AC Level 2 single-phase charging only. For DC fast charging solutions, please refer to ChargePapa’s DC-Link adapter series.
Q: Is the CP-KL-ADP-022 certified?
A: Yes. This adapter carries CE (Conformité Européenne) and FCC (Federal Communications Commission) certifications, confirming compliance with safety and electromagnetic interference standards.
This adapter is designed for AC Level 2 single-phase charging only. Do not use with DC fast chargers or three-phase AC stations.
Always verify that your charging station output does not exceed 32A / 250V before use. Exceeding rated parameters may cause damage and will void the warranty.
