ChargePapa Omni-Link | GB/T to Type 1 (J1772) Right Angle Adapter Pro (50A / AC Only)
Couldn't load pickup availability
Charge Your US-Spec J1772 EV at Chinese GB/T Stations — Up to 50A AC Level 2
The ChargePapa Omni-Link Pro connects Chinese GB/T AC charging infrastructure to US-specification J1772 (Type 1) vehicles — including Ford, Rivian, Nissan, Lucid, and GM EVs. Rated at 50A Max / AC 110V–250V with IP54 weather protection and an ergonomic right-angle design for easier plug access. Built with PC+PA66+GF25% flame-retardant housing, silver-plated copper pins, 1500V withstand voltage, and >10,000 mechanical cycle life.
Conversion Direction
GB/T AC Charging Station (China) → SAE J1772 / Type 1 EV Port (US Spec)
AC Level 2 Only · 50A Max · Single Phase · IP54 · Right Angle
⚠️ AC Level 2 Only: This adapter supports AC Level 2 charging only. It is NOT compatible with GB/T DC fast charging infrastructure. Use only at GB/T AC charging stations. Do not use at DC fast chargers.
| SKU | CPCADA0028 |
| Connector (Input) | GB/T 20234.2 (AC) — Chinese Charging Standard |
| Connector (Output) | SAE J1772 (Type 1) — US/Japan EV Standard |
| Rated Current | 50A Max |
| Operating Voltage | AC 110V – 250V |
| Phase Type | Single Phase |
| IP Rating | IP54 |
| Withstand Voltage | 1500V |
| Housing Material | PC + PA66 + GF25% (Flame Retardant) |
| Pin Material | Silver-Plated Copper |
| Mechanical Life | >10,000 Cycles |
| Operating Temperature | -30°C to +50°C · Humidity 5~95% · Altitude ≤2000m |
| Charging Mode | AC Level 2 Only |
| HS Code | 8544.42.90 |
Designed for US-specification J1772 EVs and PHEVs temporarily or permanently located in China, where GB/T AC charging is the dominant standard. Ideal for expats, long-term visitors, and imported vehicle owners who need daily access to China's extensive GB/T charging network.
| Make | Model | Year | Port Type |
|---|---|---|---|
| Ford | Mustang Mach-E / F-150 Lightning | 2020–2024 | SAE J1772 |
| Rivian | R1T / R1S | 2021–2024 | SAE J1772 |
| Nissan | Leaf (US Import) | 2011–2024 | SAE J1772 |
| Lucid | Air (US Spec) | 2021–2024 | SAE J1772 |
| Chevrolet | Bolt EV / Bolt EUV | 2017–2024 | SAE J1772 |
| Toyota | bZ4X / RAV4 Prime (US Import) | 2019–2024 | SAE J1772 |
⚠️ US-spec J1772 vehicles only. Not compatible with GB/T DC fast charging stations. Verify your vehicle's onboard charger accepts 50A input before use.
Connector standards compliance: GB/T 20234.2 (AC) input · SAE J1772 (Type 1) output · IP54 weather protection rating.
For certification documentation requests, please contact ChargePapa support with your SKU (CPCADA0028).
⚠️ Critical Usage Note: For AC Level 2 charging only. Do NOT use at GB/T DC fast charging stations. For US-spec J1772 vehicles only. Always verify your vehicle's onboard charger rating before use. Keep connector dry and inspect for damage before each use. Mechanical life rated at >10,000 insertion cycles.
