ChargePapa Omni-Link | Tesla to J1772 (Type 1) Right Angle Adapter Pro (50A / AC Only)
Couldn't load pickup availability
Use Tesla Chargers with Any J1772 EV — Up to 50A AC Level 2
The ChargePapa Omni-Link Pro lets Ford, Rivian, Chevrolet, Honda, and other J1772-standard EVs access Tesla Wall Connectors and Destination Chargers. Rated at 50A Max / AC 110V–250V with IP54 weather protection, it delivers reliable Level 2 charging in any environment. Built with PC+PA66+GF25% flame-retardant housing, silver-plated copper pins, and 1500V withstand voltage for long-term durability.
Conversion Direction
Tesla Wall Connector / Destination Charger → J1772 (Type 1) EV Port
AC Level 2 Only · 50A Max · Single/Split Phase · IP54
⚠️ AC Level 2 Only: This adapter supports AC Level 2 charging only. It is NOT compatible with Tesla Superchargers (DC Fast Charging). Do not attempt to use at Supercharger stations.
| SKU | CPCADA0031 |
| Connector (Input) | Tesla Proprietary (Wall Connector / Destination Charger) |
| Connector (Output) | SAE J1772 (Type 1) |
| Rated Current | 50A Max |
| Operating Voltage | AC 110V – 250V |
| Phase Type | Single / Split Phase |
| IP Rating | IP54 |
| Withstand Voltage | 1500V |
| Housing Material | PC + PA66 + GF25% (Flame Retardant) |
| Pin Material | Silver-Plated Copper |
| Mechanical Life | >10,000 Cycles |
| Operating Temperature | -30°C to +50°C · Humidity 5~95% · Altitude ≤2000m |
| Charging Mode | AC Level 2 Only |
| HS Code | 8544.42.90 |
Designed for J1772 (Type 1) standard EVs and PHEVs that need access to Tesla's extensive Destination Charger and Wall Connector network. Ideal for Ford Mustang Mach-E owners at Tesla-equipped hotels, Rivian drivers at Tesla Destination locations, and Chevy Bolt users wherever Tesla chargers are available.
| Make | Model | Year | Port Type |
|---|---|---|---|
| Ford | Mustang Mach-E / F-150 Lightning / Escape PHEV | 2020–2024 | SAE J1772 |
| Rivian | R1T / R1S | 2021–2024 | SAE J1772 |
| Chevrolet | Bolt EV / Bolt EUV | 2017–2024 | SAE J1772 |
| Honda | Prologue / Clarity PHEV | 2018–2024 | SAE J1772 |
| Toyota | bZ4X / RAV4 Prime / Prius Prime | 2019–2024 | SAE J1772 |
| Volkswagen | ID.4 / ID.4 AWD | 2021–2024 | SAE J1772 |
⚠️ Verify your vehicle's onboard charger accepts 50A input. Actual charging speed is limited by the vehicle's onboard charger capacity. Not compatible with Tesla Superchargers.
Connector standards compliance: Tesla Proprietary input · SAE J1772 (Type 1) output · IP54 weather protection rating.
For certification documentation requests, please contact ChargePapa support with your SKU (CPCADA0031).
⚠️ Critical Usage Note: For AC Level 2 charging only. Do NOT use with Tesla Superchargers or any DC fast charging infrastructure. Always verify your vehicle's onboard charger rating before use. Ensure the Tesla Wall Connector is configured for the correct amperage. Keep connector dry and inspect for damage before each use. Mechanical life rated at >10,000 insertion cycles.
Warranty & Assurance
Warranty & Assurance
2-Year Comprehensive Warranty.
We cover all internal component failures. If a fault occurs, we provide remote diagnosis and free replacement units or parts. No return shipping required for confirmed defects.
Shipping & Lead Time
Shipping & Lead Time
Factory Direct Shipping.
• Processing (QC): 3-5 Business Days
• Global Transit: 8-20 Business Days
• Tracking provided via email upon dispatch.
Global Shipping & Fulfillment
Shipped Direct: Estimated timelines vary by product type.
Total turnaround may vary because product categories have different warehouse stock levels, quality-control procedures, and dispatch preparation cycles before shipment.
Adapters & Accessories
12-22 Business Days
Handling 4-7 business days + transit 8-15 business days.
Portable, Home & DC Chargers
15-29 Business Days
Handling 7-14 business days + transit 8-15 business days.
🏭 The Direct Process
To ensure safety and performance, ChargePapa products go through inspection, preparation, and dispatch coordination before shipment. Different product types may require different warehouse allocation and quality-control turnaround before release.
PART 1 Estimated Handling Time Before Dispatch
Tier 1
Adapters & Accessories
4-7 Business Days
For charging adapters, connector accessories, and related small parts. This handling window remains unchanged.
Tier 2
Portable Chargers, Home Chargers & DC Chargers
7-14 Business Days
For portable EV chargers, home charging stations, and DC charger models including DC SVC-TG and DC EVC-ZG. Additional preparation time is required before dispatch.
PART 2 Transit Time (8-15 Days)
Global Transport
8-15 Days
International transport via Air Freight, Sea Freight, or Land depending on destination and local delivery conditions.
Estimated Timeline by Product Type
Longer total timelines do not mean inactive processing. They reflect differences in stock allocation, warehouse readiness, product inspection workload, and dispatch turnover by category.
| Product Type | Handling Time | Transit Time | Estimated Total |
|---|---|---|---|
| Adapters & Accessories | 4-7 business days | 8-15 business days | 12-22 business days |
| Portable EV Chargers | 7-14 business days | 8-15 business days | 15-29 business days |
| Home Charging Stations | 7-14 business days | 8-15 business days | 15-29 business days |
| DC Chargers / DC SVC-TG / DC EVC-ZG | 7-14 business days | 8-15 business days | 15-29 business days |
Remote Areas & Extended Delivery
Deliveries to remote regions, island destinations, low-frequency carrier zones, or special-route areas may require additional transit time beyond the standard estimate.
Depending on destination access and local logistics availability, shipments may be routed through a combination of air freight, sea freight, and land transport to complete final delivery safely and efficiently.
Logistics & Protection
All international orders are automatically insured against loss or damage. We handle claims with transport partners at no extra cost to you.
We utilize a combination of Air, Sea, and Land transport networks to ensure secure delivery to your specific address.
Tracking numbers are generated after handling is complete. Adapters and accessories usually receive tracking within 4-7 business days, while portable chargers, home charging stations, and DC charger orders may require 7-14 business days before tracking becomes active.
We handle export paperwork. However, specific local import duties or taxes are the recipient's responsibility.
* Product-specific handling times apply before transit begins.
* Orders placed on weekends or holidays will be processed on the next business day.
* Remote regions, islands, and special-route destinations may require additional transit time.
* During high-volume periods such as Black Friday or New Year, handling and transit may require additional time.
* Neither party shall be liable for delays resulting from force majeure events, including natural disasters, strikes, customs holds, or transport disruption.
Need a status check on your order timeline?
Contact our logistics team if your tracking update is taking longer than the estimated handling window for your product type.
✉ info@chargepapa.com
Will this fit my car?
Will this fit my car?
Please verify your car's port type (Type 1 vs Type 2) before purchasing. If unsure, send a photo of your charging port to our chat support.
