This is one of the most frustrating EV charging scenarios: the charger shows Ready, the connector is plugged in, but the car is not accepting charge — zero current draw, battery percentage not moving. No fault light. No error code. Just nothing.
In most cases, this issue comes down to the control pilot handshake between the EVSE and the vehicle — and the fault is on the vehicle side more often than the charger side. But there are eight distinct causes, and the fix depends on which one applies. Use the diagnostic table below to identify yours first.
This is a focused companion to the ChargePapa EV Charger Troubleshooting Guide — which covers all 10 common charging failure types including no power, breaker trips, and fault lights. If your charger has no lights at all, start there.
Quick Diagnostic: Find Your Cause
Match your symptom to the most likely cause, then jump directly to the fix:
| What you see | Likely cause | Jump to fix |
|---|---|---|
| Car display says "Scheduled" or shows a clock icon | Active charge schedule | Cause #1 |
| Plug does not click into place | Connector not fully seated | Cause #2 |
| Charger stays amber, battery % does not move | Pilot signal not accepted | Cause #3 |
| Charge port door won't open or latch won't release | Port lock engaged | Cause #4 |
| Car shows "Charge Limit Reached" or battery icon is full | Charge limit already met | Cause #5 |
| Debris, moisture, or bent pins visible in port | Port contamination or damage | Cause #6 |
| Worked yesterday, same setup, now nothing | Vehicle BMS or software fault | Cause #7 |
| Works on another charger, not this one | Charger pilot signal fault | Cause #8 |
Cause #1 — Active Charge Schedule in the Vehicle
What's happening: Most modern EVs include a scheduled charging feature that delays the start of a session until a set time — typically overnight off-peak hours. When a schedule is active, the pilot handshake completes normally (hence the green/ready status), but the vehicle instructs the EVSE to wait. The charger is doing exactly what it's told.
How to fix
- Open your vehicle's infotainment or companion app → Charging Settings.
- Find "Scheduled Charge", "Departure Time", or "Off-Peak Charging" and disable it, or tap "Charge Now" / "Override".
- On Tesla and some Hyundai/Kia models, tapping the charge port area on the touchscreen forces an immediate start.
What confirms this is the cause: The vehicle's display shows a scheduled time or clock icon next to the charging status. Disabling the schedule causes charging to begin within 10–15 seconds.
Cause #2 — Connector Not Fully Seated
What's happening: The IEC 62196 (Type 2) and SAE J1772 (Type 1) standards require a positive mechanical latch before the pilot signal circuit closes. If the connector is 90% inserted but not latched, the charger may show a partial ready state while the vehicle receives no pilot signal at all.
How to fix
- Unplug completely. Inspect the connector face and charge port for any obstruction.
- Reinsert firmly and listen for an audible click. On Type 1 (J1772), release the handle trigger after insertion to engage the latch.
- After reinsertion, the vehicle's charging indicator should illuminate within 5–10 seconds.
What confirms this is the cause: You did not hear a click on the original insertion. After re-seating with a click, charging begins immediately.
Cause #3 — Pilot Signal Not Accepted by the Vehicle
What's happening: The pilot signal is a 1 kHz PWM signal sent by the EVSE on the CP (Control Pilot) pin. It tells the vehicle the charger is present and communicates available current. If the vehicle's onboard charger (OBC) doesn't respond — due to a software glitch, cold soak, or a weak 12V auxiliary battery — the charger stays in the "waiting for vehicle" state (amber on ChargePapa units, IEC 61851 State B).
How to fix
- Unplug from the vehicle, wait a full 60 seconds (the OBC needs time to fully reset), then reconnect.
- Also power-cycle the charger: switch off the circuit breaker for 30 seconds, then back on. This resets the EVSE's pilot signal generator.
- If the vehicle's 12V auxiliary battery is weak or discharged, the OBC may not respond correctly. A 12V battery below ~11.5V can prevent AC charging from initiating entirely.
What confirms this is the cause: The charger LED stays amber for more than 30 seconds after plugging in. After a full power-cycle of both the charger and vehicle, charging begins normally.
Cause #4 — Charge Port Lock Engaged
What's happening: Many EVs lock the charge port when the vehicle is locked, or when a specific setting is enabled. If the port lock is engaged before the connector is inserted, the connector may not seat fully — or the vehicle may refuse to initiate charging as a security measure.
How to fix
- Unlock the vehicle before inserting the connector. On most EVs, the charge port unlocks automatically when the vehicle is unlocked.
- Check vehicle settings for a "Charge Port Lock" or "Cable Lock" option. Set it to lock only when charging is active, not always.
What confirms this is the cause: The charge port door is stiff or won't open fully before insertion. Unlocking the vehicle and re-inserting resolves the issue immediately.
Cause #5 — Vehicle Charge Limit Already Reached
What's happening: The battery is already at or above the configured charge limit. The charger handshakes normally, but the vehicle immediately signals that no current is needed. This is correct behavior — not a fault. Most EVs default to an 80% limit to protect long-term battery health.
How to fix
- Check the current state of charge (SOC) on the vehicle display or app. If it's at or above your set limit, the vehicle won't draw current.
- To charge higher for a trip, temporarily raise the charge limit in vehicle settings (e.g., 80% → 100%), then plug in again.
What confirms this is the cause: The vehicle's battery display shows a percentage at or above the configured limit. Raising the limit causes charging to begin immediately.
Cause #6 — Charge Port Contamination or Damage
What's happening: Dust, moisture, insects, or physical damage to the charge port pins can prevent the pilot signal circuit from completing. Even a small amount of moisture on the CP or PE pins can cause a high-resistance connection that the EVSE interprets as "no vehicle present."
How to fix
- Inspect the charge port with a flashlight. Look for debris, corrosion, moisture, or bent/pushed-back pins.
- Use compressed air to clear debris. Do not use water, WD-40, or contact spray directly in the port.
- If moisture is present, allow the port to dry completely (30–60 minutes) before attempting to charge again.
What confirms this is the cause: Visible debris or moisture in the port. Charging resumes after cleaning and drying.
Cause #7 — Vehicle BMS or Software Fault
What's happening: The Battery Management System (BMS) or onboard charger software has entered a fault or protection state. This can happen after a deep discharge, an interrupted OTA update, extreme temperatures, or a recent DC fast charge session that stressed the battery.
How to fix
- Perform a full vehicle soft reset: power completely off via the settings menu, wait 2 minutes, then power back on.
- Check for pending OTA software updates. Some vehicles will not charge while an update is queued or partially installed.
- If the vehicle has been below 5% SOC for an extended period, the BMS may require a slow pre-conditioning phase before accepting normal current. Leave it plugged in for 30 minutes and check again.
What confirms this is the cause: The issue appeared suddenly with no hardware change. A full vehicle reset resolves it. The vehicle's fault log may show a stored charging-related DTC.
Cause #8 — Charger Pilot Signal Fault
What's happening: In a small number of cases, the EVSE itself has a fault in its pilot signal circuit. This is rare in new units but can occur after a power surge, firmware issue, or physical damage to the control board. The key diagnostic: the vehicle charges normally on a different EVSE, but not on this one.
How to fix
- Test the vehicle on a different charger. If it charges normally, the issue is with the EVSE.
- Test the suspect charger on a different vehicle if possible. If it also fails on a second vehicle, the EVSE pilot circuit is faulty.
What confirms this is the cause: Vehicle charges on a different EVSE. The suspect charger fails on multiple vehicles.
Using an Adapter? Read This First
If you are using an adapter between the charger and the vehicle (Type 2 charger with a Type 1 vehicle, or a NACS adapter), connector compatibility issues can also cause a "ready but not charging" state. The adapter must support the full pilot signal circuit — passive mechanical adapters that only convert the physical connector shape without correctly wiring the CP and PP pins will not work.
ChargePapa's EV charging adapters are fully wired for pilot signal compatibility. If you are using a third-party adapter and experiencing this issue, the adapter is the most likely cause.
Frequently Asked Questions
Why does my EV charger say Ready but not charge?
A "Ready" status on the charger means the EVSE has power and is waiting to supply current — it does not confirm the vehicle is drawing current. The most common reasons are: an active charge schedule in the vehicle, the charge limit already being met, or a pilot signal handshake failure. Use the diagnostic table above to identify your specific cause in under two minutes.
Is this a charger problem or a vehicle problem?
In the majority of "ready but not charging" cases, the fault is on the vehicle side — a charge schedule, charge limit, port lock, BMS state, or OBC issue. The fastest way to confirm: test the vehicle on a different charger. If it charges normally, the vehicle is fine and the EVSE is the issue. If it also fails on a different charger, the vehicle requires diagnosis.
Can a weak 12V battery stop AC charging?
Yes — this is an underappreciated cause. The 12V auxiliary battery powers the vehicle's control systems, including the onboard charger (OBC) electronics. If the 12V battery is below approximately 11.5V, the OBC may not have enough power to respond to the pilot signal, even if the high-voltage traction battery is fine. If your EV is older or has been sitting unused for weeks, have the 12V battery tested before assuming the charger or traction battery is at fault.
What does amber light mean on a ChargePapa charger?
An amber solid LED means the EVSE is sending the pilot signal and waiting for the vehicle to respond (IEC 61851 State B). This is normal for a few seconds after plugging in. If it stays amber for more than 30 seconds, the vehicle is not accepting the pilot signal — see Cause #3.
My car charged fine last night but won't charge today — same charger, same outlet. Why?
Intermittent failures with no hardware change are almost always caused by a vehicle software or BMS state — a pending OTA update, a BMS protection mode triggered by temperature or a recent fast charge, or a charge schedule that was silently re-enabled. Start with a full vehicle soft reset (Cause #7) and check for pending updates.
Is it safe to leave the charger plugged in if it shows Ready but isn't charging?
Yes — a charger in the "ready" or "waiting for vehicle" state is not supplying current and poses no safety risk. The EVSE only energizes the power contacts after the full pilot signal handshake completes. You can safely leave it connected while you diagnose the issue.
