Hyundai IONIQ 5 V2L: Complete Setup Guide, What You Can Power, and Which Adapter (2026)

ChargePapa Knowledge Hub May 2026 · V2L Field Guide
Vehicle-to-Load · US & EU Edition

Hyundai IONIQ 5 V2L:
Complete Setup Guide,
What You Can Power & Which Adapter

EU Output

3.5 kW

US Output

1.8 kW

Battery Pack

77.4 kWh

The IONIQ 5 has two V2L outputs most owners don't know about — and one of them doesn't even need an app. This guide covers both methods, the exact adapter for your market, what the output can actually run, and how to verify your trim before you order anything.

Compatibility note: V2L availability varies by trim level and model year. Data sourced from the Hyundai IONIQ 5 Owner's Manual (2022–2026 editions). Verify for your specific configuration before purchase.

Does the Hyundai IONIQ 5 Need an Adapter for Tesla Superchargers?

The IONIQ 5 charging adapter question depends on model year — the port changed between 2024 and 2025.

The 2022–2024 IONIQ 5 uses a CCS1 port and requires a NACS-to-CCS1 DC adapter to access Tesla Superchargers. Built on Hyundai's 800V E-GMP platform, the IONIQ 5 Long Range supports DC fast charging up to 220 kW. At 1,000V DC (Supercharger V3 operating voltage), that equals 220A continuous through the adapter. A 500A-rated adapter carries that load at 44% of rated capacity.

The 2025 IONIQ 5 switched to a native NACS port and plugs directly into Superchargers without an adapter. It does, however, need a J1772-to-NACS adapter to access J1772 Level 2 stations, which still represent the majority of public AC charging locations.

Model Year Port Supercharger Access Level 2 (J1772) Access
2022–2024 IONIQ 5 CCS1 Needs NACS→CCS1 DC adapter Native
2025 IONIQ 5 NACS Native Needs J1772→NACS adapter

For the 2022–2024 IONIQ 5: ChargePapa DC-Link NACS-to-CCS1 (CPCADA0030) — 500A / 1,000V DC / IP65 / UL94 V-0

For the 2025 IONIQ 5: ChargePapa Tesla-Link J1772-to-NACS (CPCADA0017) — 80A Max / IP54 / UL94 V-0

01

Does Your IONIQ 5 Have V2L?

V2L is not standard on every IONIQ 5 trim. Check your build before ordering an adapter.

Market Trim V2L Included
US SE Standard Range ⚠ Varies — check window sticker
US SE Long Range ✓ Standard
US SEL / Limited / AWD ✓ Standard
EU Standard Range ⚠ Market-dependent
EU Long Range ✓ Standard
EU All AWD variants ✓ Standard
Confirm in 60 seconds: Look under the front bumper — equipped trims have a J1772 socket flush-mounted near the front lip. If it's there, V2L hardware is installed. Alternatively, check your window sticker or owner's manual Section 7 (US edition).
02

Two Ways the IONIQ 5 Delivers V2L

The IONIQ 5 is unique among V2L-capable EVs because it offers two independent discharge paths.

Method 1 — Simplest

Exterior V2L Socket

Under the front bumper · J1772

A dedicated J1772 socket flush-mounted behind a flap under the front bumper. Permanently in discharge mode — no app, no settings menu, no activation required. Use the V2L-US adapter for this port.

  1. Open the front socket flap
  2. Plug in the V2L adapter
  3. Power flows immediately

Method 2 — All V2L Trims

Charging Port Discharge

CP Signal Trigger · 2,000Ω resistor

Uses a 2,000Ω resistor on the Control Pilot (CP) pin to signal the bidirectional charger into discharge mode. Works on all V2L trims. EU users: use the V2L-EU or V2L-Pro adapter.

  1. Insert V2L adapter into charging port
  2. IONIQ 5 detects the 2,000Ω CP signal
  3. AC power routes out through the port
03

Which Adapter Do You Need?

Market Port Adapter Output
US Front J1772 exterior socket V2L-US 15A / 1.8 kW
EU Type 2 charging port V2L-EU 16A / 3.5 kW
EU CCS2 combined port V2L-Pro 16A / 3.5 kW
Why US output (1.8 kW) is lower than EU (3.5 kW): Grid voltage only. US: 120V × 15A = 1.8 kW. EU: 230V × 16A = 3.7 kW. The IONIQ 5's inverter delivers full-rated output for each grid.
EU buyers — V2L-EU vs V2L-Pro: Identical output. V2L-EU uses a Type 2 plug with 4–5 EU outlets — better for camping. V2L-Pro uses a CCS2 plug with a more secure mechanical lock. Both work on the IONIQ 5 EU charging port.

ChargePapa Store

Shop the Solution

The adapters referenced in this guide — matched to your market and port type.

FAQ

Frequently Asked Questions

Can the Hyundai IONIQ 5 charge at Tesla Superchargers?

Yes. The 2022–2024 IONIQ 5 has a CCS1 port and accesses Tesla Superchargers with a NACS-to-CCS1 DC adapter. Peak draw is 220 kW (220A at 1,000V DC). A 500A-rated adapter runs at 44% capacity — well within thermal limits for a full session. The 2025 IONIQ 5 has native NACS and plugs in directly.

What adapter does the Hyundai IONIQ 5 need?

It depends on your model year. 2022–2024: CCS1 port — needs a NACS-to-CCS1 DC adapter for Supercharger access, J1772 Level 2 is native. 2025: NACS port — Superchargers are native, needs a J1772-to-NACS adapter for most public Level 2 stations.
