ChargePapa Omni-Link | Type 2 to Type 1 (J1772) Right Angle Adapter Pro (50A / Single Phase)
Couldn't load pickup availability
Omni-Link Adapter Path
Best for Type 1 / J1772 EV drivers using Type 2 AC charging sources.
Will this fit my setup?
Use this adapter when your charging cable or station has a Type 2 / IEC 62196-2 AC plug, and your EV has a Type 1 / SAE J1772 charging port.
AC LEVEL 2 PATHType 2 / IEC 62196-2 AC source → Type 1 / SAE J1772 vehicle inlet
For compatible J1772 / Type 1 EVs charging from a Type 2 AC charging source.
50A max · AC 110V–250V · single-phase
The adapter does not create extra power. Actual speed still depends on source output, voltage, cable path, and the vehicle onboard AC charger.
Not for DC fast charging
Do not use this with CCS DC fast chargers, Tesla Superchargers, GB/T DC, CHAdeMO, or any DC fast-charging network.
Need Type 1 / J1772 source → Type 2 vehicle instead?
This is the reverse direction. Choose the Type 1 / J1772 to Type 2 adapter path instead.
Standards & Certifications
| SKU | CP-TQ-ACM-001 |
| Charging source | Type 2 / IEC 62196-2 AC source |
| Vehicle inlet | Type 1 / SAE J1772 vehicle inlet |
| Charging mode | AC charging only |
| Rated current | 50A MAX |
| Working voltage | AC 110V–250V |
| Phase | Single phase |
| Maximum power reference | Up to approximately 12.5kW at 250V when the source and vehicle support 50A |
| Protection rating | IP54 |
| Form factor | 90° right-angle body |
| Certification | CE |
When This Adapter Helps
Use it when the charger-side plug is Type 2 and the session is AC charging.
Choose this path when the vehicle-side charging port is SAE J1772 / Type 1.
The right-angle form factor can help where cable clearance near the vehicle inlet is limited.
Type 2 AC → NACS / Type 1 / GB/T Product Line
| Model | Current | Best for |
|---|---|---|
| CP-TQ-ACM-009 | 50A Right Angle Pro · AC only | Type 2 AC source → Tesla / NACS vehicle inlet path |
| CP-TQ-ACM-001 This product | 50A Right Angle Pro · single phase | Type 2 AC source → Type 1 / J1772 vehicle inlet path |
| CP-TQ-ACM-008 | 50A Right Angle Pro · single phase | Type 2 AC source → GB/T vehicle inlet single-phase path |
| CP-TQ-ACM-002 | 50A Right Angle Pro · three phase | Type 2 AC source → GB/T vehicle inlet three-phase path |
| CP-KL-ADP-018 | 32A · AC only | Type 2 AC source → Tesla / NACS vehicle inlet compact path |
| CP-KL-ADP-017 | 32A · AC only | Type 2 AC source → Type 1 / J1772 vehicle inlet compact path |
| CP-KL-ADP-020 | 32A single phase | Type 2 AC source → GB/T vehicle inlet single-phase path |
| CP-KL-ADP-019 | 32A · AC 400V three phase · ~22kW | Type 2 three-phase AC source → GB/T vehicle inlet path |
FAQ
It works from a Type 2 / IEC 62196-2 AC charging source to a Type 1 / SAE J1772 vehicle inlet.
No. This is an AC adapter only. It is not for CCS DC fast chargers, Tesla Superchargers, GB/T DC, CHAdeMO, or any DC fast-charging session.
No. The 50A value is the adapter-side ceiling. Actual charging speed depends on the Type 2 source, voltage, cable path, and the vehicle onboard AC charger.
No. This product is for Type 2 AC source to Type 1 / J1772 vehicle inlet. If your charging source is Type 1 / J1772 and your vehicle has a Type 2 inlet, choose the reverse adapter path.
